State-of-the-Art Technology in Natural Full Band Width Reproduction
The QLS is a SOTA line source using ribbon and moving coil drivers. It is available with or with out sub woofers, for a true full range band pass
experience.
|
 |
| | PRELIMINARY DATA SHEET |
| |
| | Amplitude Variation VS. Frequency | 39 HZ TO 41K KHZ, +/- 3 DB - MAIN ARRAY
Extends to 19 HZ with QLS SUB WOOFERS |
| | Nominal impedance | 7 OHMS |
| | Sensitivity | 2.83 Volts yields 95 DB at one meter |
| | Power handling | 400 watts continuous / 1000 watts peak |
| | | |
| | Driver complement | 9 X 6.5" TRUE RIBBONS
9 X 5.5" MID WOOFER-MID RANGE
EFFECTIVE VERTICAL LINE SOUCE OF FIVE FEET
2 SUB WOOFERS, WITH POWERED 1000 WATT
PLATE AMPLIFERS, WITH PARAMETRIC EQ
TOTAL OF FOUR 12" WOOFERS, 2 PER SUB |
| | Dimensions | 72 " X 22" X 16" LINE SOURCE
29" X 26" X 14" SUB WOOFER |
| | Weight | QLS 325 pounds net / 375 crated
Sub-woofer 175 net / 225 crated |
|
